Soft close Hinges- Ebco brand ‘0’ crank Hinges Or THICK DOOR HINGE – SOFT CLOSE
- Available in Full Overlay, Half Overlay & Inset
- Soft Close mechanism prevents shutters from banging.
- Max. Opening : 95°
- Max. Shutter Size: 34″ x 22″ (850mm x 550mm) for 2 hinges.
- Shutter Thickness: 18mm to 30mm.
- Shutter Cavity: Ø40mm, 14 deep, Cavity 4mm from Edge.
- Finish: Nickel Plated.
SPECIFICATIONS
| Model | Code | Type | ‘A’ | Finish |
| Thick Door Hinge Full Overlay – Soft Close | HTD1-SC | Full Overlay | 40.0 | Nickel Plated |
| Thick Door Hinge Half Overlay – Soft Close | HTD2-SC | Half Overlay | 40.0 | |
| Thick Door Hinge Inset – Soft Close | HTD3-SC | Inset | 35.0 |
FITTING INSTRUCTIONS
- Drill out the cavity in the shutter as per the dimensions in Fig. 1.
- Fit the cap into the shutter cavity and screw on the hinge at right angle to the edge of the shutter.
- Mark hole in the cabinet for mounting plate as per Fig.2 and screw on the mounting plate.
- Now, align the shutter with the cabinet and click-on to the mounting plate. Any play or gap in cabinet can be adjusted in the bracket.
- By loosening the bracket screws, the shutter can slide horizontally and also be pivoted for varying pressure.
